AW100S9Z

Features

  • Light weight and compact
  • Single sequential actuation and "contact actuation" nailing change mechanism
  • For wire collated nails
  • Easy top loading pop-out magazine
  • Tool-less adjustment in driving depth
  • Comfortable soft trigger covered with double-molded elastomer
  • Rubber grip

Specifications

Voltage (by areas) Single-phase AC 50/60Hz - 220V to 240V
Power Input 1,400W
Max. Discharge Pressure 7.0MPa (1MPa: 10.2 kgf/cm2)
Max Permissible Pressure 10.0MPa
Max Feed Pressure 0.7MPa
Max Water Discharge 5.5L/min
Permissible Temperature 40°C or less
Water Feeding Method Faucet connection type
Dimensions (L x W x D) *1 305 x 245 x 465mm (12" x 9-5/8" x 18-1/4")
Weight *2 5.4kg (11.9lbs.)
Standard Accessories Trigger gun, High-pressure hose (5m), Variable nozzle, Detergent bottle nozzle, Water feed connector, Nozzle cleaner pin, Cord holder, Gun holder, Handle (with 2 attachment screws)
