Capacity
|
Blade Dia. - 255mm (10")
|
|
Capacity
|
(H x W) Cross Cut 0º - 59 x 144mm or 89 x 101mm - (2-5/16 x 5-21/32 or 3-1/2 x 3-31/32")
|
|
Capacity
|
(H x W) Miter Cut 45º - 59 x 102mm or 89 x 70mm - (2-5/16 x 4 or 3-1/2 x 2-3/4")
|
|
Capacity
|
(H x W) Miter Cut 52º - 59 x 89mm or 89 x 54mm - (2-5/16 x 3-1/2 or 3-1/2 x 2-1/8")
|
|
Capacity
|
(H x W) Bevel Cut 45º - 41 x 144mm (1-5/8 x 5-21/32")
|
|
Capacity
|
Compound Mter 45º and Beve 45º - 41 x 102mm (1-5/8 x 4")
|
|
Power Input
|
1,520W
|
|
No Load Speed
|
5,000/min.
|
|
Miter Angle:
|
Right - 0 – 52º
|
|
Miter Angle:
|
Left - 0 – 52º
|
|
Bevel Angle
|
Left - 0 – 45º
|
|
Positive Angle Stop
|
0, 15, 22.5, 31.6 and 45º
|
|
Dimensions
|
460 x 628 x 561mm - (18-1/8 x 24-3/4 x 22-3/32")
|
|
Weight
|
11.9kg (26.2 lbs.)
|
|
Standard Accessories
|
Blade, Dust Bag, Vise Assy, Sub Fence,Wrenches
|
